Parameter	Condition	G802-90	G802-180	G802-270	G802-360	unit
Measuring range		0~90	0~180	0~270	0~36 0	°
Temperature drift	-40~85°	0.02	0.02	0.02	0.02	°/°C
Resolution		0.05	0.05	0.05	0.05	°
Accuracy	-40~85°C	0.3	0.5	0.6	1	°
Long term stability	-40~85°C	0.32	0.53	0.65	1.1	°
Response time	slow/fast	600/200 μS
Power-on start time		0.2s
Output signal	Rload=240Ω	0~20mA, 4 20mA optional
Noise		3mV
Midpoint offset	midpoint output (Approach left and right)	4~20mA output 12mA 0~20mA output 10mA
Average working hours	≥55000 hours/time
Impact resistance	20000g, 0.5ms, 3rd axis
Anti-vibration	10grms、2～2000Hz
Operating temperature	-40~85°C
Waterproof level	IP66 (can be customized IP67)
Cable	Standard 1.5 meter length, wear-resistant, oil-proof, wide temperature, shielded cable 3 * 3 mm2
Weight	120g (excluding packaging box)
