G830

The G830 series is high precision angle sensor, with an accuracy of 0.02°, supporting setting range and adopting integrated MEMS technology, low power consumption, built-in high-precision 16 bit A/D converter, multiple outputs RS232, TTL, RS485, RS422, CAN, 0-5V, 0-10V, 4-20mA, 0-20mA and 0-24mA are optional. By utilizing magneto electric induction technology, precision bearings, differential array magnetic sensitive components, and non-contact measurement of the shaft, the parallel magnetic field strength of a permanent magnet installed at one end of the shaft is sensed and processed by MCU. Linear correction, temperature compensation, self-developed filtering algorithm, and programmable intelligent control with multiple different slope settings are implemented to improve measurement accuracy.

GT 50

This product can determine the azimuth of the target or the prism which installed on the instrument without the help of the surveying point. There is no special installation deviation requirement before north seeking and it can determine high accuracy true north in all installation direction. This instrument can be used in the field of subway surveying or construction, coal mine surveying, tunnel construction, etc.

UF500

UF500 are high performance and cost-effective fiber optic gyroscopes based IMU combined with either with quartz flexible accelerometer or MEMS accelerometer, which can be used for navigation, control, and dynamic measurement. It has the advantages of small size, light weight, no moving parts, high reliability, and long service life. It can be widely used in aviation, aerospace, ships, weapons, coal mine measurement, automotive electronics and other fields.

UF600

UF600 are high performance and cost-effective fiber optic gyroscopes based IMU combined with either with quartz flexible accelerometer or MEMS accelerometer, which can be used for navigation, control, and dynamic measurement. It has the advantages of small size, light weight, no moving parts, high reliability, and long service life. It can be widely used in aviation, aerospace, ships, weapons, coal mine measurement, automotive electronics and other fields.

Parameter	Conditions	G830-90	G830-180	G830-270	G830-360	Unit
Measuring range⁽¹⁾		0~90	0~180	0~270	0~360	°
Zero temperature drift⁽²⁾	-40～85°	0.002	0.002	0.002	0.002	°/℃
Resolution⁽³⁾		0.01	0.01	0.01	0.01	°
Accuracy⁽⁴⁾	-40～85℃	0.02	0.03	0.04	0.05	°
Linearity		0.035	0.035	0.035	0.035	%FS
Power-on start time		0.2				s
Response time	Slow/Fast	500/200μS
Output signal^{(5) (6)}	Rload=240 Ω	0~20mA, 4~20mA optional
Noise		5mV
Midpoint offset	midpoint output (Approach left and right)	4-20mA output 12mA 0-20mA output 10mA 0-24mA output 12mA
Average working hours	≥55000 hours/time
Impact resistance	20000g, 0.5ms, 3 times/axis
Anti-Vibration	10grms, 2～2000Hz
Operating temperature	-40～85℃
Waterproof level	IP66 (can be customized IP67)
Cable	Standard 1.5 meter length, wear-resistant, oil-proof, wide temperature, shielded cable 3*0.3mm2
Weight	180g (excluding packaging box)
